TRX500FM2

PROVEN ON NZ FARMS

PATRIOT RED
OVERVIEW

TRX500FM2

The hardworking TRX500 FM2 matches the TRX500 FM1 feature for feature but adds Electric Power Steering (EPS) to create an ATV that is even easier to operate. Whether you’re working on the farm or miles away from it, the EPS makes twisting and turning in tight quarters strain-free, stability over rugged terrain no sweat, and long hours on the saddle unnoticeable.

To provide unmatched reliability there are a host of developments including a chassis that is 20% stiffer than the previous model, new CV boots improve the durability of running gear, a revised swing-arm and new adjustable longer travel suspension add to the package. There is no question this ATV is built tough. The hard wearing body work gives the model a distinctive, no nonsense appearance. The 5-speed manual transmission with reverse is also built to last and designed to give you maximum control. Front diff lock will help this model crawl out of anywhere. The impressive weight carrying and towing capacity means the 500FM2 simply works where other ATVs can’t.

For New Zealand’s demanding farming conditions the 475cc liquid-cooled, four-stroke, fuel-injected engine is committed to getting the job done. Just like you.

BOOK A TEST RIDE

GALLERY

TRX500FM2

WHY CHOOSE A HONDA

WHY CHOOSE A HONDA


For over 40 years Honda has been a fixture on farms around New Zealand. With a range of products designed for New Zealand conditions you can rest assured that no matter the task your Honda is up for it.

Simply click on one of the buttons below to hear real stories from real Honda customers or check out just some of the great benefits of using a Honda on farm in New Zealand.

CUSTOMER STORIES HONDA BENEFITS

FEATURES

TAKE A CLOSER LOOK

/10

BNZ FINANCE

BNZ FINANCE


Honda proudly partners with the BNZ to offer a great range of finance options. Talk to your Honda dealer today to find the best finance solution for your needs. We can help finance you into your new Honda whether you are looking at a new ATV, Side by Side, Off-road Bike, Road Bike or Scooter.

FIND OUT MORE
SPECIFICATIONS

YOUR BIKE IN DETAIL

TRX500FM2
Engine
Engine Type Liquid-cooled OHV longitudinally mounted single-cylinder four-stroke
CC Rating 475cc
Bore and Stroke 92.0mm x 71.5mm
Ignition Full-transistorized type with electronic advance
Transmission
Starter Electric with optional auxiliary recoil
Gearbox 5 speed manual with Reverse
Wheels, Suspension & Brakes
Suspension Front Independent double-wishbone; 185 mm travel
Suspension Rear Swingarm with single shock; 185 mm travel
Brakes Front Dual hydraulic 190mm discs
Brakes Rear Sealed 160mm mechanical drum
Tyres Front Maxxis 25 x 8-12
Tyres Rear Maxxis 25 x 10-12
Dimensions & Weight
Wheelbase 1,268mm
Seat Height 869mm
GroundClearance 190mm
Kerb Weight 293kg
Fuel Capacity 14.7 litres including 4.9 litres reserve
Dimensions 2,103mm(L) x 1,205mm(W) x 1,219mm(H)
